Overview
Precision in Colour Accuracy for Professional Monitoring, the Accsoon CineView M7 4K60 7″ Smart Touchscreen Wireless Transmission Monitor offers a 7 inch LCD Touchscreen with Android-based UI. It features 3G-SDI & HDMI 2.0 Cross Conversion, 3G-SDI & HDMI 2.0 Simultaneously Outputs, and Up/Down Convert HD/4K Video. Additionally, it includes a LUT Box for Real-Time Look Application, 4K60 Video Inputs & Outputs, SD Card Support, USB 3.0 for External Storage, and Microphone and Headphone Jacks.
The monitor also allows users to Receive Wireless Video from CineView Transmitters with a Transmission Range of 1200ft/350m for Dual-Band connection and a Latency of less than 60ms. It supports streaming, cloud-upload, and sharing via Built-in Wi-Fi, as well as PD, DC & NP-F power options. Compatible with CineView QUAD/HE/SE/2SDI/Master 4K, the Accsoon CineView M7 4K60 7″ Smart Touchscreen Wireless Transmission Monitor is a versatile tool for professional monitoring needs.
Summary
Screen Size: 7 Inch
Resolution: 1920 x 1080
Aspect Ratio: 16:9
Inputs:
HDMI
SDI
Outputs:
HDMI
SDI
Included in box
1x CineView M7 Pro
4x 2.4GHz/5Ghz Antenna
1x User Manual
About the Accsoon Cineview M7 Pro
CineView M7 Pro
All-In-One Wireless Smart Monitoring Ecosystem
Master Colour Accuracy True To Source Precision
7” OLED Cinema grade display equipped with full-touch interface. Precision colour details crafted for professional creators.
Cinema Grade Colour Accuracy
Precisely calibrated to meet professional filmmaking standards with cinematic depth and colour accuracy.
Support Custom Screen Calibration
1D/3D LUTs Calibration: Compatible with Calman®/ColourSpace®/Calibrite®
Adjustable Gamma (2.0-2.6)
Traditional RGB Gain Control
Precision Colour Mapping Workflow
Rec.709 D65 Gamut Mapping Engine
Edge-Lit Backlight System, Precision Light & Shadow Control
Achieving high brightness is easy, but maintaining accurate colours is challenging. CineView M7 Pro features a 1000:1 ultra-high contrast ratio combined with a fully laminated high-transmittance display, effortlessly handling both dark and bright scenes. Build with Edge-Lit backlight system with intelligent brightness control enables pixel-level precision, delivering true-to-life colour reproduction without distortion.
High Bright Fully Laminated Display – True Colours Under Direct Sunlight
CineView M7 Pro is equipped with high transparency screen, enhanced by exclusive DXC coating, increasing light transmittance to 99% while significantly reducing reflectivity. Even in bright outdoor environments, the screen maintains exceptional clarity and colour accuracy.
All in One Wireless Workstation
CineView M7 Pro features integrated long-range wireless video transmitter and receiver capabilities, seamlessly connecting to any Accsoon CineView transmitter. It leverages Accsoon’s patented Dual-Band transmission technology for ultra-low latency wireless monitoring. Nail every shot with cinematic grade tools like LUT box, false colour and waveforms-all controlled through customizable buttons.
Compatibility with CineView TX/RX system* up to DCI 4K60 wireless monitoring
* CineView Master 4K, CineView 2 SDI, CineView SE/HE/Quad
One Step Ahead Redefining Smart Monitoring
CineView M7 Pro powered by 8K high-performance processors and a smart operating system, is designed to adapt to the evolving needs of modern production.
Smart Evolution: Your Portable Production Workstation
Network connectivity, intuitive interaction, and file management with efficiency
GPU+NPU based computing system designed for higher image process capabilities
500% Smoother UI responsiveness
200% Faster image processing
Seamless Interaction, everything under your control
Intuitive Interface responsive, smartphone-like menus
In-Cell Touch Display thinner, lighter with faster touch response times
Single/Multi-Touch Support
Smart File Management transfer, organize, and process files seamlessly
Instant File Transfer & Share
Built-in Wi-Fi enables camera-to-cloud uploads, direct file sharing
Pro-Grade Live Streaming
RTMP/SRT Live Streaming with LUT burnt-in Live streaming made easy without capture card or PC
Smart and Future-Proof
Built on future-proof operating systems designed to adapt to the evolving needs of modern production
On Set Monitoring, Reimagined
CineView M7 Pro delivers cinematic standard calibrated colour with 127-point 3D LUT precision.
Its LUT Box function enables multi-screen colour consistency via SDI/HDMI outputs, revolutionizing on-set colour workflow.
Unrivalled Display Colour Precision
.cdl file support
Effortlessly import and apply 3D LUTs up to 127 points
Higher accuracy with 3D LUTs tetrahedral interpolation
LUT burnt-in monitoring, recording, streaming, and cloud sharing
LUT BOX
Real-time LUT box, applying transforms to HDMI, SDI, or WiFi outputs, or burning LUTs directly into recorded footage
Format Conversion Flexibility
Engineered with groundbreaking architecture, CineView M7 Pro delivers high processing ability to handle 961+ video format combinations effortlessly – from 4K60 to 1080P, SDI & HDMI cross-conversion, even different frame rate outputs.
Aerospace-Grade Aluminium Body
A premium grade solid design for additional protection
Quad-Antenna Dual-Band Architecture
Accsoon’s patented transmission technology ensures rock-solid wireless reliability
Smart Cooling with Speed Control
Professional Accessories*
Custom cage rig, durable protection and easy portability
*sold separately
DISPLAY
Display Screen 7″ TrueVision Backlight LCD
Touchscreen Ultra high resolution capacitive touchscreen
Resolution 1920 × 1080 pixels
Length-Width Ratio 16:9
Brightness 1000 nits
Contrast Ratio 1000:1
Viewing Angle 176°/176°
Backlight Type LED
Screen Colour Calibration Supported
LUT SUPPORT
LUT 1D and 3D LUTs supported
1D: up to 1024 points
3D: up to 127 points
INPUTS & OUTPUTS
Video Input Port HDMI 2.0
3G-SDI
Video Output Port HDMI 2.0
3G-SDI
HDMI VIDEO FORMATS
HDMI Video Input Format 4K DCI (4096×2160): 23.98/24/25/29.97/30/50/59.94/60
4K UHD (3840×2160): 23.98/24/25/29.97/30/50/59.94/60
1080p: 23.98/24/25/29.97/30/50/59.94/60
1080i: 50/59.94/60
720p: 50/59.94/60
HDMI Video Output Format 4K DCI (4096×2160): 23.98/24/25/29.97/30/50/59.94/60
4K UHD (3840×2160): 23.98/24/25/29.97/30/50/59.94/60
1080p: 23.98/24/25/29.97/30/50/59.94/60/100/120
1080i: 50/59.94/60
720p: 50/59.94/60
SDI VIDEO FORMATS
SDI Video Input Format 1080p: 23.98/24/25/29.97/30/50/59.94/60 Level A/B
1080i: 50/59.94/60
SDI Video Output Format 1080p: 23.98/24/25/29.97/30/50/59.94/60 Level A
1080i: 50/59.94/60
POWER
DC Port 6.0~16.8V
5.5mm x 2.1mm
Centre positive
Compatible Battery Compatible with NP-F550, NP-F750, NP-F970 type batteries
USB-C Power Input Port PD 9V/3A, 12V/3A, 15V/3A
USB-C Power Output Port Maximum: 5V/2A
AUDIO
Microphone/Headphone Jack 3.5mm
Microphone Input Audio Sampling 16bit, 48KHz
POWER CONSUMPTION
Power Consumption 12W~28W (varies according to actual applications)
BUILD
Housing Aluminium alloy
Heat Dissipation Active + Passive Cooling
WIRELESS
Transmission Frequency Dual-Band 2.4GHz + 5GHz
Wireless Transmission Latency 60ms
Wireless Transmission Distance Dual-Band connection: 350 metres
App connection: 100 metres
ENVIRONMENT & DIMENSIONS
Work Environment Temperature -10°C – 40°C
Weight (Antennas Excluded) 494g
Dimensions (Antennas Excluded) 182.2 × 120.7 × 31.5mm
Precision in Colour Accuracy for Professional Monitoring
7 inch LCD Touchscreen with Android-based UI
3G-SDI & HDMI 2.0 Cross Conversion
3G-SDI & HDMI 2.0 Simultaneously Outputs
Up/Down Convert HD/4K Video
LUT Box | Real-Time Look Application
4K60 Video Inputs & Outputs
SD Card Support
USB 3.0, Supports External Storage
Microphone and Headphone Jacks
Receive Wireless Video from CineView Transmitters
Transmission Range is 1200ft/350m for Dual-Band connection
Latency is less than 60ms
Stream, Cloud-Upload, Share via Built-in Wi-Fi
Supports PD, DC & NP-F power
