Product Description
AVMATRIX EAGLE P20-12G 4K Professional Broadcast PTZ Camera, 1/1.8″ CMOS Sensor, 8.3 Megapixels, 20x Optical Zoom, 12X Digital Zoom, 2D&3D Noise Reduction, 360° Infrared Remote Control
EAGLE P20 adopts a new ROBOTIC concept appearance & U Type design, more stable and more smoothly in Pan/Tilt move. It will provide users with real 4K(0W60 ultra-high-definition video experience with more really, more colorful, more clear.
KEY FEATURES
– 20X optical zoom lens
– 4K Ultra-High-Definition ultimate picture quality
– Max support dual 12G-SDI video synchronous output
– Support VISCA/UDP/ONVIF/PELCO/P, PELCOD/UVC
– Live VR/AR video production
– Max Support 255 Presets
– Double Color Tally Light
– 360° infrared remote control
SPECIFICATIONS
– CMOS Sensor: 1/1.8″ CMOS
– Effective Pixels: 8.3 Megapixels
– Optical Zoom: 20x Optical Zoom/12X Digital Zoom
– Focus Length: f=7.1~141.3mm
– HFOV: 3.6°(T) ~ 59.2°(W)
– Iris: F1.61 ~ F5.19
– Min Illumination: 0.05 lux (F1.61)
– Digital Noise Reduction: 2D&3D Noise Reduction
– Focus mode: Manual/Auto/Z- Trigger
– Iris mode: Manual/Auto
– BLC: 1-8/Off
– Picture adjustment: Brightness, Hue, Saturation, Contrast, Sharpness
– Video Output Interface: HDMI2.0, 12G-SDI, RJ45, USB3.0
– Control interface: 1x RS232 IN, 1x RS232 Out, 1x RS422 IN, 1x RS422 Out, 1x RJ45
– Network Interface: 1000M Internet Access(10/100BASE-TX)
– Power Interface: DC-038 Outlet (DC12V)
– Pan Rotation Angle: -175°~ +175°
– Tilt Rotation Angle: -30°~ +90°
– Horizontal rotation speed range: 0.1~100°/s
– Vertical rotation speed range: 0.1~80°/s
– Presets: Max Support 255 Presets
– Power Adapter: AC100V~AC240V Input, DC12V/2A Output
– Input Voltage: DV12V
– Power Consumption: 15W
– Storage Environment: -10°C ~ +60°C / 20% ~ 95%
– Working Environment: -10°C ~ +50°C / 20% ~ 80%
– Weight: 2970g
Photo Sensor Technology CMOS
Video Capture Resolution 1080p
Maximum Focal Length 7.1 Millimeters
Video Capture Format MPEG
Included Components No
Minimum Focal Length 141.3 Millimeters
Photo Sensor Size 1/1.8-inch
