Kiloview N3 HD Video Encoder/Decoder

OVERVIEW
Please Note: Video encoder only. Images are for illustrative purposes only.

A Professional NDI Video Converter
Kiloview N3 3G-SDI/NDI High Bandwidth converter is a bi-directional converter that supports 3G-SDI video input (encoder) to NDI High Bandwidth with 3G-SDI loop through for view on monitor, or 3G-SDI video output (decoder) from NDI High Bandwidth.
Featured with powerful functions such as PoE, built-in big tally light, PTZ control, 3.5mm audio line in/out, multi-channel audio, intercom functions, Kiloview N3 is your best choice to get access to the fabulous NDI world for professional broadcast-grade IP production.

Why NDI?
The NDI protocol is a high-performance standard that enables anyone to use real-time, ultra-low-latency video on existing IP video networks.

NDI Webcam Input
Easily designate Kiloview NDI encoders as the video input source in popular desktop video applications like Google Hangouts, GoToMeeting, Skype, Skype for Business, WebEx, Zoom, Teams and…

INCLUDED IN BOX
1x NDI Converter
1x Type C Power Cable
1x Type C To Type A Cable
1x Warranty Card
1x Power Adapter
1x Hot Show
1x Quick Start Guide

About The Kiloview N3 HD Video Encoder/Decoder
Please Note: Video encoder only. Images are for illustrative purposes only.

A Professional NDI Video Converter

Kiloview N3 3G-SDI/NDI High Bandwidth converter is a bi-directional converter that supports 3G-SDI video input (encoder) to NDI High Bandwidth with 3G-SDI loop through for view on monitor, or 3G-SDI video output (decoder) from NDI High Bandwidth.

Featured with powerful functions such as PoE, built-in big tally light, PTZ control, 3.5mm audio line in/out, multi-channel audio, intercom functions, Kiloview N3 is your best choice to get access to the fabulous NDI world for professional broadcast-grade IP production.

Why NDI?

The NDI protocol is a high-performance standard that enables anyone to use real-time, ultra-low-latency video on existing IP video networks.

NDI Webcam Input

Easily designate Kiloview NDI encoders as the video input source in popular desktop video applications like Google Hangouts, GoToMeeting, Skype, Skype for Business, WebEx, Zoom, Teams and more using the free NDI® webcam input tool.

Perfect for your video production

The N3 supports up to 3G-SDI HD video input to NDI High Bandwidth and loop through for monitoring, at the same time it supports NDI High Bandwidth to 3G-SDI output. It’s a versatile NDI converter.

It’s an NDI encoder, it’s also an NDI decoder

Both NDI encoding and decoding can work on this tiny device (100*80*28mm), you got two in one. Switching the working mode on the UI to choose the mode you need; it can easily meet all your different workflows.

*N3’s encoding and decoding functions are mutually exclusive, and cannot be used at the same time

Audio Intercom

Kiloview N3 supports 3.5mm analog audio line in/out or embedded audio, up to 16CH audio supported.

It also supports voice intercom by USB headset with Kiloview Intercom server.

Video source auto-detecting

Thanks to the NDI discovery server, your video can be easily found and connected by users from another network when registered to the designated server.

Seamless Switching without Lagging

When decoding NDI sources, with Kiloview unique technology, there will be no lag when switching the output NDI videos.

Control with a USB keypad

In decoder mode, you can preset the NDI sources from number 0-9. Connect the decoder with a USB keypad, you can easily choose the output source with a single press.

Or you can even use the USB Keypad to control a PTZ camera- the cheapest PTZ Keyboard you can get.

PTZ control and Big-sized tally

Kiloview N3 supports PTZ control through USB to serial RS232/485/422. It also supports PTZ control over IP, no extra cable required

N3 has a big-sized while bright and distinct Tally for PVW/PGM indication – all is to make perfect cooperation for your team.

Power it as you wish

With PoE, the N3 can be powered with a single cable connection. With the design of wide DC input range from 5V to 18V, it can also be easily powered by USB power or camera battery.

Various mounting methods

It has an exquisite design, small and light-weight, which can be easily attached to the camera by a threaded screw.

N3 3G SDI NDI bi-directional converters in rack mounted forms

The groove design on both sides facilitates the rackmount installation in 1U/3U

Compatible with TriCaster, vMix, OBS and other platforms, so your video production can be carried out anytime, anywhere.

Video input 1x3G-SDI
Video output 1x3G-SDI（Loop or decoding output）
Audio port 1×3.5mm
Network 1xRJ45 1000Mbps Ethernet port (with PoE)
Video resolution Up to 1080p60 (backward compatible with SD/HD/VESA)
NDI® codec capacity 1xNDI® encoding or 1xNDI® decoding
NDI® codec feature NDI High Bandwidth HD encoding, typical bitrate: 125Mbps@1080p60
LED indicator Tally light, power light and status connection light
Power PoE, DC, D-Tap (camera) optional. 5-18V wide range supported
Voice intercom Customization
PTZ Control Network PTZ and Serial Port
DHCP Support
Management Web UI and remote management with KILOVIEW KiloLink Server
Power consumption 6w
Working Temperature -20~45℃ (Storage temperature: -20~70℃)
Dimension 100x80x24mm (3.94”x3.15”x0.94”)/0.2 kg

Plug-and-play operation, SDI to NDI®, or NDI® to the screen;
Equipped with SDI input and output interfaces, which can be looped out on the monitor during streaming, or output
SDI signal during decoding;
Preset 10 outputs, including 9 decoding addresses and 1 blank preset box (customizable background color), and USB extended keyboard for switching.
High quality and low latency transmission
Encoding and decoding both support 1080p60 (HD) resolution, backward compatible with SD/HD/VESA resolution and other special resolutions;
Ultra-low latency, end-to-end latency is less than 100ms;
FULL NDI high-quality encoding ensures excellent image quality, and lossless audio encoding ensures high-fidelity sound quality;
Accurate clock and intelligent algorithm ensured video frame, image and audio synchronization.
Built-in large-size Tally light to indicate PGM (program output) or PVW (pre-monitor output) status;
Support for PoE (Power over Ethernet) and 5-18V DC input powered by USB, mobile power or camera battery;
Equipped with 3.5mm headset interface, support voice intercom (customization).
PTZ control with protocols of Visca/Visca over IP/Pelco (special PTZ control protocols can be customized);
Integrated with IMS software to realize functions such as remote management and control, NDI stream management and distribution, centralized call management, and large-scale program production management;
SDK/API provided for secondary development.
