Litepanels Astra IP 2×1 LED Panel – SY EU

£1,950.00 Ex VAT



The Bi-Colour 2×1 LED panel is a popular choice in the industry, with a wide range of features and options. It has a weatherproof rating of IP65, making it suitable for use in various environments. With a high output of 5,500 lux at 10ft/3m and a 30˚ beam angle, it provides powerful and accurate white light. The panel also comes with a diffusion panel and has a CRI/TLCI average of 95. It is lightweight at just 17.2lb/7.8kg and can be powered by a variety of mobile options. The panel also has integrated Bluetooth and an optional DMX module, as well as a range of modifiers and accessories.

The Astra IP series has evolved to offer all-weather performance, making it suitable for use in even the most demanding environments. It is available in 1×1, half-size, and 2×1 fixtures, and offers intense output with a tight beam angle. The panel can be adjusted from 2,700K to 6,500K and is rated IP65, making it resistant to rain, dust, and snow. It has an integrated power supply and can be powered by Gold Mount, V-Mount, or BP-U batteries. The Astra IP 2×1 model is particularly versatile, with a high output of 5,500 lux and the option for precise control with the DMX module. Overall, the Astra IP series is a reliable and powerful choice for indoor and outdoor productions.

This text is summarized by AI
1x Astra IP 2×1 Bi-Colour LED Panel (Standard Yoke, EU Power Cable)
1x Astra IP 2×1 Medium Diffuser (937-0025)

About The Litepanels Astra IP 2×1 LED Panel – SY EU
All-Weather Performance

The industry’s best-selling Bi-Colour LED panel has evolved. Astra IP is tough and water-resistant, delivering intense output in lightweight 1×1, half-size and 2×1 fixtures with fast set up for high-performance broadcast lighting in demanding environments.

Power and Punch

Lighting for even the brightest location. With ultra-efficient LEDs and a tight beam angle, Astra IP produces output with impact. Command powerful, flattering, and accurate white light at any intensity, with or without diffusion. Adjust from 2,700K to 6,500K with instant confirmation on the clear LCD screen to match multiple fixtures with confidence.

Ready for Action

From the studio to the street, Astra IP always performs. Rated IP65, Astra IP defies rain, dust, or snow, for seamless operation, whatever the weather. Built tough with an integrated power supply, and optional Gold Mount, V-Mount and BP-U battery plates, Astra IP is the fast fixture that never backs down in any conditions.

Astra IP 2×1

Astra IP 2×1 delivers practical and high-quality white light for indoor and outdoor productions. The powerful 5,500 lux output of Astra IP 2×1 at 10ft/3m provides flexibility for diffusion or positioning at a distance. The optional Astra IP DMX module allows for precise control in a grid, while its IP65 rating and low 250W power draw allow use in tough outdoor conditions.

LED Panel Bi-Colour
Beam Angle 30°
Colour Temperature Range 2700°-6500°K
Daylight (5600°K) lux @10ft/3m 5500 (No diff)
Tungsten (3200°K) lux @10ft/3m 5200 (No diff)
CRI Average 95
TCLI Average 95
Interchangable Diffusers Domed (not included)
Medium (included)
Optics 30° custom TIR lens
Lighting Control Modes CCT/FX with LCD menu control
Preset Options Preset CCT modes with quick select
Customizable user presets with quick select
Dimming Control Constant Current 0-100% Continuous (flicker free)
Remote Control Options Bluetooth [integrated], DMX, RDM [requires separate module]
Fan Control Yes
USB Updates Yes
Ambient Temp Operation -4° to 113° F / – 20° to + 45° C
Estimated LED lifetime 50,000+ hrs
Versions Manual
Weight 17.2lbs / 7.8kg (including yoke and power supply)
Mounting Method 28mm Junior Pin
Dimensions (without yoke)
Height 12.3″ / 31.3cm
Width 24.9″ / 63.2cm
Depth 4.8″ / 12.3cm
Dimensions (with yoke)
Height 16.8″ / 42.6cm
Width 27″ / 68.7cm
Depth 4.8″ / 12.3cm
Nominal Power Draw 250W
Power Supply Internal
Mains Input PowerCON True 1, 100-240 VAC / 50-60Hz
DC Input 12-30V
IP Rating IP65

Bi-Colour 2×1 LED panel (2,700K to 6,500K)
IP65 weatherproof rating
High output of 5,500 lux at 10ft/3m with 30˚ beam angle
Diffusion panel included
CRI/TLCI average 95
Lightweight at just 17.2lb/7.8kg
Compatible with a wide range of mobile power options
Integrated Bluetooth with optional DMX module
Range of optional modifiers and other accessories
