Overview
This is the first camera under the new Z Cinema umbrella which Nikon are also classing the Z mount RED cameras under as well. The ZR is based around the Z6 III but of course has a few refinements to make it more focused for motion acquisition and some new features that RED have had a hand in, and thats why its got both of their branding on the camera.
The ZR camera is designed to cater to the needs of filmmakers and videographers, with features specifically tailored for motion acquisition. With input from RED, the camera offers enhanced capabilities for capturing high-quality video content, making it a versatile tool for professionals in the film industry.
Summary
Dynamic Range: 15+ Stops
Lens Mount: Nikon Z Mount
Recording Formats:
NIKON N-RAW
PRORES RAW
REDCODE RAW
Internal ND: No
Audio Inputs: 3.5mm Mic input
Battery Mount / Type: Nikon EN
Media Type:
CFexpress Type B
SD
Sensor: Full Frame
Weight: 0-2kg
Wi-Fi: Yes
Included in box
1x Nikon ZR Cinema Camera
1x BS-D1 Digital Accessory Shoe Cover
1x EN-EL15c Rechargeable Li-ion Battery
1x BF-N1 Body Cap
1x AN-DC26 Mirrorless Camera Strap
1x USB Cable with Type-C Connectors at Both Ends
About the Nikon ZR
This is the first camera under the new Z Cinema umbrella which Nikon are also classing the Z mount RED cameras under as well. The ZR is based around the Z6 III but of course has a few refinements to make it more focused for motion acquisition and some new features that RED have had a hand in, and thats why its got both of their branding on the camera.
Imagine being able to capture professional footage anywhere, without the need for a large crew. Discover the ZR—insane full-frame image quality, class-leading built-in audio and unbeatable versatility. A ground breaking compact 6K cinema camera for filmmakers at all levels.
Redcode Raw (R3D NE)Renowned RED colour science, built-in. Full control over ISO, exposure and colour in post.
32-bit Float Audio
Wide dynamic range audio recording in-camera.
Built-in Stabilization
Powerful built-in stabilization with any lens—up to 7.5 stops.
High-quality Monitor
Built-in 4 inch Vari-angle DCI-P3 display with touch control.
Versatile Z Mount
Widest, shallowest full-frame mirrorless lens mount supports a vast selection of lenses.
Advanced Nikon Autofocus
9-subject detection autofocus, with automatic tracking of people, animals and vehicles—powered by deep learning.
Photographic Tech Specs
Camera Type Digital camera with support for interchangeable lenses
Sensor Type 24.5 MP Full-Frame CMOS
Sensor Size 35.9mm x 23.9mm
Dynamic Range 15+ Stops
Mount Type Z Mount
Lens Compatibility Accepts FTZII Mount Adapter with F-mount lenses.
Capable of supporting third-party lenses, however when using non-Nikon
adapters with third-party lenses, some functions may not be supported.
Battery Type EN-EL15c, Compatible with external V Mount batteries via USB-C
Weight 1.19 lbs (Without battery and cards)
Dimensions (LxWxD) 133mm × 80.5mm × 48.7mm
Max Recording Time 125 minutes
Media Primary CFexpress Type-B
Media Secondary Micro SD (UHS-I)
Monitor Size 4
Monitor Colour DCI-P3
Monitor Type Vari-angle LCD
Monitor Brightness 1000 cd/m^2
I/O Power Data Type-C USB (USB 3.2)
I/O External Monitoring Type-D HDMI
I/O Audio Capture Line Input / Digital Hot Shoe
I/O Audio Monitoring 3.5mm Headphone Jack
I/O Digital Accessory Shoe hot-shoe with sync and data contacts
I/O Tripod Socket 1/4 inch
Codecs REDCODE RAW (R3D NE) / 12-bit
NIKON N-RAW / 12-bit
PRORES RAW HQ
PRORESS 422 HQ
H.265 / 10-bit / 8-bit
H.264 / 8-bit
Audio Recording 32-bit float
24-bit
5 Audio Pickup Patterns via Nokia OZO Audio, (Available in H.265, H.264)
Log Profiles RED Log3G10 (R3D NE)
Nikon N-Log (N-RAW, PRORES RAW, PRORES 422, H.265)
ISO Sensitivity Dual Base ISO – RED Log3G10: 800 / 6400 (Dual Native ISO)
Dual Base ISO – Nikon N-Log: 800 / 6400 (Dual Native ISO)
Colour Management Load up to 10 LUTs. Supports 17-point,
33-point, 65-point LUTs. Compatible with 24, 25, 30, 60p Frame Rates.
Picture Controls Cloud Picture Controls by RED: CineBias,
CineBias-T Cool Atmosphere, CineBias-C Crisp Teal Contrast,
CineBias-CC Noir Vibes, CineBias-WC Grit & Glow,
CineBias-TC Green Edge Experimental, CineBiasOffset,
CineBias Achromic, CineBias BleachBypass.
Autofocus 9 Autofocus Subject Detection Modes
(People (eyes, face, head, upper body), Birds, Dogs, Cats, Cars,
Motorcycles, Bicycles, Trains and Airplanes).
Programable Autofocus Speed, Sensitivity and Position Recall
In-Body image stabilization Nikon Vibration Reduction with 7.5 Stops
Features Time-lapse video recording, electronic Vibration Reduction,
time codes, REC lamp, N-Log and HDR (HLG) video, waveform display,
red REC frame indicator, video recording display zoom
(50%, 100%, 200%, and 400%), extended shutter speeds (modes S and M),
and dual-format (proxy video) recording for RAW video;
option to view video recording info available via i menu; breathing compensation, Hi-Res Zoom
Camera To Cloud Compatible with Adobe Frame.io via Nikon NX MobileAir app.
Photographic Tech Specs
Megapixels 24.5
Exposure Modes Auto Programmed auto with flexible program (P)
Shutter-priority auto (S) Aperture-priority auto (A) Manual (M)
User Modes U1, U2, U3, and U4 (user setting mode)
File Formats NEF (RAW): JPEG: HEIF: Supports RAW + Secondary Format Capture
Shutter Speed Range Electronic shutter range: 1/16000 sec to 900 sec
Release Mode Single frame, continuous low-speed, continuous highspeed,
continuous high-speed (extended), high-speed frame capture + with Pre-Release Capture, self-timer
Approximate Frame Advance Rate* Continuous low-speed: Approx. 1 – 7 fps
Continuous high-speed: Approx. 16 fps
Continuous high-speed (extended): Approx. 20 fps
High-speed frame capture + (C15): Approx. 15 fps
High-speed frame capture + (C30): Approx. 30 fps
High-speed frame capture + (C60): Approx. 60 fps
High-speed frame capture + (C120): Approx. 120 fps
* Maximum frame advance rate as measured by inhouse tests.
ISO Range ISO 100 to 64000
White Balance Auto (3 types), natural light auto, direct sunlight,
cloudy, shade, incandescent, fluorescent (3 types), flash,
choose colour temperature (2500–10,000 K), preset manual
(up to 6 values can be stored), all with fine-tuning
Picture Controls Flexible Picture Control, Rich Tone Portrait,
Deep Tone Monchrome, Flat Monochrome, Storage for custom Picture Controls,
Selected Picture Control can be modified, Vivid, Standard, Portrait, Neutral,
Monochrome, Landscape, Flat, Creative Picture Controls (Dream, Morning,
Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic,
Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon),
Auto, Storage for Cloud Picture Controls.
Timelapse Mode Yes
Wi-Fi Yes
Bluetooth Yes
Connectivity Nikon SnapBridge App.
Camera to Cloud Nikon Imaging Cloud
Up to 6K/60p in-camera recording
Flexible frame rates and resolutions. From cinematic 24p to 240p extreme slow motion. From richly detailed 6K to crisp, compact 1080p.
Semi-stacked full-frame sensor
Wide dynamic range and fast read-out speeds that effectively minimise rolling shutter distortion.
Renowned RED colour science: an exclusive R3D NE codec from RED allows immense freedom in post and enables ZR footage to be matched with video shot on a RED camera system.
Large, bright 4-inch Vari-angle touchscreen monitor
Covers the DCI-P3 colour gamut and boasts a generous 16:10 display format. Functions are controlled with soft, quiet screen taps, and up to 10 3D LUTs can be loaded into the camera for viewing on the monitor while filming.
Dual Base ISO of 800/6400
When shooting in Log3G10. The sensor’s wide 15+ stop dynamic range is maintained at both base ISOs.
In-camera 32-bit float audio recording
Capture sound freely using the camera’s internal mics, or a compatible external mic, and adjust the levels in post without clipping.
Cinematic video modes and custom RED Picture Controls
4 creative video modes and 9 custom RED presets for content with a cinematic look and feel straight out of the camera.
Fast, intelligent AF
Quick, accurate, reliable, and customisable. Intelligent subject detection and tracking, custom wide-area AF, and selectable AF speeds for smooth, repeatable focus transitions.
5-axis in-body image stabilisation
Nikon’s sensor-shift Vibration Reduction keeps footage steady
Focus-breathing compensation
For smoother, more natural-looking transitions.
Long recording times
An innovative body design efficiently and quietly dissipates heat. Light, tough: the ZR weighs approx. 540 g (body only) and is fully weather sealed.
Z mount for flexibility in lens choice
Attach any Nikkor Z lens, any Nikon F-mount lens, and a wide range of third-party lenses.
Expandable
Nikon and partner brand accessories make it possible to put the ZR at the heart of an extensive video rig.
New ME-D10 digital shotgun mic
Compatible with the 32-bit float audio format and boasts a 77 dB signal-to-noise ratio for distortion-free sound.
