Swit BIVO-200 B-Mount Battery

£560.00 Ex VAT

BIVO-200

Category:

OVERVIEW
The BIVO-200 is a versatile 14.4V/28.8V Bi-voltage B-mount battery with a high capacity of 196Wh. It can handle a constant high load of 200W and has a fast charging capability of 33.6V 100W. It also features 2 D-tap outputs, an OLED power info display, and a built-in LED torch. With multiple circuit protections, this battery is strong and reliable, able to withstand a 1.2m drop off.

The BIVO-200 is suitable for use with ARRI cameras and other compatible cinegears. It can output either 14.4V or 28.8V depending on the camera’s B-mount plate, eliminating any risks of misuse. With a charging time of approximately 3 hours on a SWIT PC-P461B B-mount charger, this battery is a part of the BIVO series family, which includes different sizes and capacities to meet the needs of filmmakers. The BIVO-200 also has a LED torch that can be activated with a double press of the power check button to assist in dark production environments.

SUMMARY
Battery Capacity: 196Wh
Battery Capacity: 150-300Wh
Battery Indicator: Yes
Battery Mount / Type: B-Mount
Voltage:
14.4v
28.8v
INCLUDED IN BOX
1x Swit 196Wh Bi-voltage B-mount Battery Pack

About The Swit BIVO-200 B-Mount Battery
14.4V/28.8V Bi-Voltage B-mount Battery

BIVO-200 is a 14.4V(10.8-16.8V) and 28.8V (22-33.6V) Bi-voltage B-mount battery, for ARRI cameras and various compatible with regular voltage cameras and cinegears. The battery will recognize the ID pin resistor value of the B-mount plate, and then output 14.4V or 28.8V, without any misuse risks.

196Wh Capacity, 200W Load

BIVO-200 battery has 196Wh large capacity, run more than 2 hours on ARRI ALEXA 35 camera. The battery provides at least 200W constant high load for cine cameras and devices.

2x D-tap Power Output

BIVO-200 provides with 2x D-tap power sockets.
When the battery works at 14.4V voltage, the D-tap outputs 11-16.8V;
When the battery works at 28.8V voltage, the D-tap output regulated 16V, to power all kinds of camera-top devices.

OLED Power Info Display

BIVO-200 battery provides an OLED screen to display battery status and power information, includes output voltage, power percentage, remaining running time, and protection warning code if any abnormal detected.

100W Super Fast Charging

You can charge 4x BIVO-200 simultaneously on SWIT PC-P461B B-mount charger, at 33.6V 3A, 100W super fast charging. The charger will take approx. 3 hours to fully charge 4x BIVO-200 batteries.

BIVO Series Family

The BIVO series Bi-voltage B-mount battery famaily has 98Wh, 160Wh, 196Wh, 290Wh, the different sizes and capacities, for stablizer handheld light weight or long time power selection.

LED Torch

You can double press the Power Check button to switch on LED torch on the rear side of the battery, to help you to find B-mount plate in dark production environment.
Double press the Power Check button again to switch the light off, and it will be automatically switched off after 30 seconds

1.2 meters Drop-off Proof

BIVO-200 battery can survive from 1.2 meters drop-off at any angles, strong and reliable for filmmakers.

Voltage 28.8V (21.6-33.6V) & 14.4V (10.8-16.8V)
Capacity 196Wh
Constant load (28.8V) 200W, 8A
(14.4V) 200W, 16A
Charging 33.6V 100W fast charging
Mount Type B-mount
D-tap ×2 14.4V status: 10.8-16.8V out, 200W load
28.8V status: 16V regulated out, 50W load
Charging Temperature 0-40°C
Discharging Temperature -20°C-50°C (Capacity and Max Load may decrease when operating below 0°)
Net weight Approx 1.1kg
Dimensions 144×100×54mm

14.4V/28.8V Bi-voltage B-mount
196Wh high capacity
200W constant high load
33.6V 100W fast charging
D-tap 11-16.8V output ×2
OLED power info display
Built-in LED torch
Strong 1.2m drop off proof
Multiple circuit protections
